47
> Change from previous revision
GA 24
Item Part No. Qty. Description Serial Numbers/Notes
1
2703216 1 Cam Case
2 2703105 1 Shaft, Cam
3 521302 6 Cam
4 463021 6 Key, Woodruff
5 520237 2 Liner, Bearing
6 520232 2 Bearing, Needle
7 520228 4 Race, Inner
8 520458 2 Spacer, 1/4”
9 520456 2 Spacer, 15/32”
10 548327 2 Retaining Ring
11 520242 2 Washer, Retaining
12 520229 2 Bearing, Thrust Needle
13 520231 2 Washer, Inner Thrust
14 520230 2 Washer, 1/8” Outer Thrust
15 520233 2 Bearing, Needle
16 548926 2 Spiral Retaining Ring
17 548272 2 Seal, Oil
18 520236 2 Cage, Bearing
19 520238 AR Shim, 0.005”
Add shims as required to obtain
0.005” to 0.015” end play
20 520239 AR Shim, 0.010”
21 520240 AR Shim, 0.020”
22 548902 8 Screw, 5/16-18 x 1” Flangelock
23 521803 6 Slinger, Oil
24 400286 6 Screw, 3/8-16 x 2-3/4” Hex Head
Torque oil slinger hardware to 18-22
ft-lbs.
25 446140 6 Lockwasher, 3/8
26 444762 6 Locknut, 3/8-16 Center
27 540094 6 Slide and Guide Assembly See 13.1
28 548905 24 Screw, 3/8-16 x 1” YS HSF G5
29 548201 2 Set Screw, 5/16-18 x 5/16”
30 548813 2 Set Screw, 5/16-18 x 1/2”
31 800113 3 Plug, 1/2-14 NPT Drain
32 4115988 1 Tab, Holding
33 400400 4 Screw, 1/2-13 x 3/4” Hex Head
To Next Page
