4 SPECIFICATIONS
en-13
4.3 MOWER SPECIFICATION ___________________________________________________
Battery: 12V, 600 CCA, Group BCI 24
Service Brake: Dynamic braking through the traction circuit
Parking Brake: Integrated in wheel motor, hydraulic release
Fuel Tank: 35 U.S. Gallons (132.5 l)
Hydraulic Tank: 33 U.S. Gallons (125 l)
Hydraulic Fluid: ISO VG68
Charge Filter: 10 Micron, 30 psi (2.06 BAR) crack bypass
Return Filter: 10 Micron, 30 psi (2.06 BAR) crack bypass
Hydraulic Cooling: Hydraulic Oil Cooler, 60 psi (4.12 BAR) crack bypass
Steering: Hydrostatic power steering, with adjustable steering wheel
Traction Drive: Variable displacement hydraulic pump to 255 in
3
(398 cc) front wheel motors and 12.5 in
3
(205.5
cc) rear wheel motors.
Cutting Unit Drive: 1.01 in
3
(16.55 cc) hydraulic motors connected to the cutting unit
Mow Speed: 0-8.5 mph (0-13.68 kph)
Transport Speed: 0-20 mph (0-32.2 kph)
Reverse Speed: 0-5.5 mph (0-8.9 kph) 2WD, 0-3 mph (0-4.8 kph) 4WD
HR9016T Cutting Performance: 16.5 acres/hr. (6.68 hectares/hr) @8.5 mph (13.68 km/hr)
4.4 HYDRAULIC SPECIFICATION _______________________________________________
Circuit Description Flow @2400 rpm engine speed
US Gallons/Minute (Liters/Minute)
Relief Valve Pressure
psi (BAR)
Forward Traction Circuit 29.1 (110.36) 4387 (302)
Reverse Traction Circuit 29.1 (110.36) 4387 (302)
Charge Pressure 312 (21.5)
Right three front deck motors
Left two front deck motors
Left wing deck motors
Right wing deck motors
13.3 (50.3)
13.3 (50.3)
13.3 (50.3)
13.3 (50.3)
3000 (207)
3000 (207)
3000 (207)
3000 (207)
Steering and Lift/Lower 5.1 (19.3) 1500 (103)
