Jacuzzi Faucet Kit User Manual

9/32" DIA.
C
L
1-1/2" DIA.
DRILL PILOT HOLE FIRST
HOLE FOR THREADED
PIPE EXTENSION
(FILL SPOUT)
INTERIOR OF BATH
9/32" DIA.
HOLE DRILLING TEMPLATE—WATER RAINBOW™
HOT WATER
FAUCET HOLE
1-1/2" DIA.
15/64"
RIB HOLE
15/64"
PILOT
HOLE
1-3/8" DIA.
BATH RIM
INTERIOR OF BATH
15/64"
PILOT
HOLE
15/64"
PILOT
HOLE
15/64"
RIB HOLE
15/64"
RIB HOLE
15/64"
RIB HOLE
DRILL PILOT HOLES
AND RIB HOLES
BEFORE DRILLING
1-1/2" DIA. HOLE
(1/2" REF)
(2-1/2" REF)
(2-1/2" REF)
CHECK TEMPLATE SCALE USING
REFERENCE DIMENSIONS BEFORE DRILLING
If scale is off, do not continue, call customer support at 1-800-288-4002 to obtain a new template
COLD WATER
FAUCET HOLE
(3" REF)
Jacuzzi Whirlpool Bath 6683000G 8/06
