55
100
6:45p
1a
1a
1a
1a
1a
3
2a
2a
2b
2b
2b
2b
1b
1b
1b
4
4
5
2
1
a
b
a
b
5
100
6:45p
2
3
1
1
1
1
1
2
2
2
3
3
1
1
1
1
1
3
3
3
JET/AIR CONTROLS J-435
The hot tub specifications are subject to change without prior notice.
The hot tub specifications are subject to change without prior notice.
J-435
Massage Selector (1-2)
• Massage selector 1 diverts pump 2 output between
jets groups 1a-1b.
• Massage selector 2 diverts pump 1 output between
jets groups 2a-2b.
Jets
• The jets labelled 3 are always active when pump 2 is in
operation.
• The jets labelled 4 are always active when pump 1 is in
operation.
Waterfall Selector (5)
• Waterfall selector 5 controls circulation pump output
to waterfall.
J-435
Air Controls Operation
• Rotate air controls 1-3 to add air to designated jet
groups.
To Next Page
