49
100
6:45p
1a
1a
2a
2a
2a
2a
2b
2b
2b
2b
1b
1b
4
3
5
2
1
a
b
a
b
5
100
6:45p
3
4
1
2
4
2
2
1 4
3
2
4
3
3
4
4
1
3
JET/AIR CONTROLS J-485
J-485
Air Controls Operation
• Rotate air controls 1-4 to add air to designat-
ed jet groups.
J-485
Massage Selectors (1-2)
• Massage selector 1 diverts pump 1 output
between jets groups 1a-1b.
• Massage selector 2 diverts pump 2 output
between jet groups 2a-2b.
Jets
• The jets labelled 3 are always active when pump
1 is in operation.
• The jets labelled 4 are always active when pump
2 is in operation.
Waterfall Selector
• Waterfall selector 5 controls circulation pump
output to waterfalls.
The hot tub specifications are subject to change without prior notice.
The hot tub specifications are subject to change without prior notice.
