Jacuzzi J19 POWER PRO - Page 2

JACUZZI
–
J1
9
POWER
PRO
Revision 12/12/22
Seat Depth
A = 26.42" (67.10cm) C = 28.44" (72.23cm)
B = 20.76" (52.73cm) D = 21.88" (55.57cm)
LISTED DIMENSIONS REPRESENT DISTANCE FROM THE TOP
OF ACRYLIC TO LOWEST POINT IN THE SEAT. TOLERANCE
±1/16’’ (0.158CM)
C
A
ACP
-
Air controller Pump
BJ- Buoyancy Jet
CHF
-
Cascading Hydro Falls
Diverter1 : Turn LEFT
to DIVERTER 2, Turn
RIGHT to seat BJ
Massage Selector/Air Control Diagram
A
ACP 1: Opens/Closes;
Air inlet to all jets in the
seat A, B
Diveter2: Turn jets
ON/OFF in seats A, B,
C, D.
D
CHF: To turn ON/OFF
Cascading Hydro fall
ACP 3: Opens/Closes;
Air inlet to seats C, D.
B
C
ACP 4: Opens/Closes;
Air inlet to all BJ
(Buoyancy jet)
B
D
