ASSEMBLY OF THE CENTER DIFF.

ASSEMBLY OF THE FRONT GEAR CASE

ASSEMBLY OF THE FRONT ARMS HOLDER

Step 2

40024

13x16x0.2mm

Shim

36053

8x16mm

Ball Bearing

.....x2

94015

4x35mm

Hex Screw

.....x2

94005

4x16mm

Hex Screw

.....x2

40011

.....x4

5x4mm

40588(B)

*Caster angle can

be changed to

A or B

4x16mm

4x12mm

Steering

Characteristics

Steering response

becomes milder.

Steering response

becomes quicker.

Caster

(High/22 Degree)

Caster

(Low/20 Degree)

*NB. use only as matched set "A"

with"A"and "B" with "B".

94036

5x4mm

Set Screw

.....x1

94026

4x12mm

Flat Head Hex Screw

.....x2

94027

4x16mm

Flat Head Hex Screw

.....x2

Step 2

40589(B)

41103

*Fill the diff oil just level with the top

of the satellite gears.

80%

Step 1

.....x8

30776

4x10mm Washer

30774

4mm

Cross Pin

.....x2

94020

3x12mm

Flat Head

Hex Screw

.....x4

40513

30776

*Use the Diff. Oil #5000 for the center diff.

*Fill the Diff. case to approx. 80% with the Diff. Oil.

30774

Tighten

*Tighten the screws

equally.

*Tighten the diff screws in this order.

*Adjust the backlash with the shims.

Step 1

Apply

Grease

40024

40533

40024

36053

41032(10T)

36053

4x35mm

4x16mm

40533

40561

Cem

3x12mm

NO.1

BAG

NO.2

BAG

NO.2

BAG
