J&W JW-H67M-USB3 User Manual

- 20 -
JW-H67M-USB3 User's Manual
• 
Setting the advanced power management conguration, optional for Enalbed, Disbaled.
• Enable Hibernation
Eanables or disables system ability to hibernate (OS/S4 sleep
state
). This option may be not
effective with sime OS. Optional for Enalbed, Disbaled.
• ACPI Sleep State
Select the highest ACPI sleep state the system will enter when the suspend button is pressed.
Optional for Suspend Disbled
、
S1(CPU Stop Clock)
、
S3(Suspend to RAM)
.
• Lock legacy Resources
Enables or disables lock of legacy resources. optional for Enalbed, Disbaled.

Press < ESC> key to return to the Advanced menu
►
RTC

Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Advanced
Wake System With Fixed Time [Enalbed] Enable or Disabe
System wake on
alarm event. When
enabled,System will
wake on the Hr::min::
sec specified.
Wake up hour
Wake up minute
Wake up second
Wake system with Dynamic Time
0
0
0
[Disabled]
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
Enable system to wake from S5 using RTC alarm.
