janitza UMG 509 User Manual

94
UMG 509
Profibus profile number 0
Byte
index
Value type Value
format
Scaling
1 1 Voltage L1-N Float 1
2 5 Voltage L2-N Float 1
3 9 Voltage L3-N Float 1
4 13 Voltage L4-N Float 1
5 17 Voltage L2-L1 Float 1
6 21 Voltage L3-L2 Float 1
7 25 Voltage L1-L3 Float 1
8 29 Current L1 Float 1
9 33 Current L2 Float 1
10 37 Current L3 Float 1
11 41 Current L4 Float 1
12 45 Effective power L1 Float 1
13 49 Effective power L2 Float 1
14 53 Effective power L3 Float 1
15 57 Effective power L4 Float 1
16 61 Cos phi (math.) L1 Float 1
17 65 Cos phi (math.) L2 Float 1
18 69 Cos phi (math.) L3 Float 1
19 73 Cos phi (math.) L4 Float 1
20 77 Frequency Float 1
21 81 Effective power sum L1-L4 Float 1
22 85 Reactive power sum L1-L4 Float 1
23 89 Apparent power sum L1-L4 Float 1
24 93 Cos phi (math.) sum L1-L4 Float 1
25 97 Effective current sum L1-L4 Float 1
26 101 Active energy sum L1-L4 Float 1
27 105 Ind. Reactive energy sum L1-L4 Float 1
28 109 THD voltage L1 Float 1
29 113 THD voltage L2 Float 1
30 117 THD voltage L3 Float 1
Factory pre-configured profiles
Profibus profile number 1
Byte
index
Value type Value
format
Scaling
1 1 Voltage L1-N Float 1
2 5 Voltage L2-N Float 1
3 9 Voltage L3-N Float 1
4 13 Voltage L2-L1 Float 1
5 17 Voltage L3-L2 Float 1
6 21 Voltage L1-L3 Float 1
7 25 Current L1 Float 1
8 29 Current L2 Float 1
9 33 Current L3 Float 1
10 37 Effective power L1 Float 1
11 41 Effective power L2 Float 1
12 45 Effective power L3 Float 1
13 49 Cos phi (math.) L1 Float 1
14 53 Cos phi (math.) L2 Float 1
15 57 Cos phi (math.) L3 Float 1
16 61 Frequency Float 1
17 65 Effective power sum L1-L3 Float 1
18 69 Reactive power sum L1-L3 Float 1
19 73 Apparent power sum L1-L3 Float 1
20 77 Cos phi (math.) sum L1-L3 Float 1
21 81 Effective current sum L1-L3 Float 1
22 85 Active energy sum L1-L3 Float 1
23 89 Ind. Reactive energy sum L1-L3 Float 1
24 93 THD voltage L1 Float 1
25 97 THD voltage L2 Float 1
26 101 THD voltage L3 Float 1
27 105 THD current L1 Float 1
28 109 THD current L2 Float 1
29 113 THD current L3 Float 1
