Jayco 2009 Melbourne - Electrical and Propane Specifications

SECTION 13
SPECIFICATIONS & GLOSSARY
94
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual motorhome may be different.
CIRCUIT BREAKERS
The following table provides generic circuit breaker alignment information. Your RV may not be
exactly the same as shown depending on model, floor plan and options.
Main 30 amp Main, incoming power to unit
A
15 amp Refrigerator, GFCI, kitchen/bath
B 15 amp Utility/converter/inverter
C 20 amp Air conditioner
D 15 amp Water heate
r
E 20 amp Convection microwave
PROPANE CONSUMPTION CHART
The following chart provides an average propane consumption information.
Appliance
Average BTU
Consumption Per Hour Kilojoiles/Hour
BBQ
g
rill 10,000 10,550
Furnace 35,000 - 40,000 36,930 - 42,200
Ran
g
e oven 7,100 7,490
Ran
g
e, front burner 9,000 9,490
Ran
g
e, rear burner 6,500 6,860
Refri
g
erator 1,200 - 1,500 1,270 - 1,580
Water heate
r
8,800 9,280
ITEM AMP SIZE TYPE APPLICATION LOCATION
Remote mirrors 1 Glass Option In line under dash - left hand side
Back-up monito
r
1.5 Glass Option In line under dash - left hand side
Power step/auxiliary start
switch/auxiliary start
solenoid
5
Blade Standard Under dash - left hand side
Dash radio
memory/auxiliary start 5 Blade Standard On battery disconnect solenoid
1 30 amp
2
15 amp
3 15 amp
4 15 amp
5 15 amp
6 15 amp
7
15 amp
8 15 amp
9 15 amp
10 15 amp
11 15 amp
12 30 amp
12-volt DC Layout
Tank heater #1/bedroom slideout motor
Bath area, tank heater switch
Monitor panel/kitchen area/water pump
Furnace/rear roof vent
Bed area
12-volt outlets/overhead cabinet lights
Refrigerator/slideout switch/propane detector/dash radio
Tank heaters #2 & #3/main slideout motor
Living area/porch/bunk lights
Trunk lights/power awning
Main slideout lights/rangehood
Front roof vent/dinette light
