SECTION 11 – ELECTRONICS CLASS C MOTORHOME
11-2
Rotate the antenna until the pointer on the directional handle aligns with the
pointer on the ceiling plate. Turn the elevating crank counterclockwise in the
DOWN direction (approximately 13 turns) until resistance is noted. The antenna is
now locked in the travel position.
DO’S
1. Check parking location for obstructions before raising antenna.
2. Carefully raise, lower and rotate. If this is difficult, check for cause.
3. Rotate slowly when selecting station and check fine tuning on TV set to make
sure it is properly adjusted.
4. Lower antenna before moving vehicle.
DONT'S
1. Don’t force elevating crank up or down.
2. Don’t rotate directional handle hard against stops.
3. Don’t travel with lift in up position.
4. Don’t leave lift part way up or down.
5. Don’t apply sealing compound or paint over top of base plate or anywhere on
lift.
Lubricating the antenna
The elevating gear should be lubricated 3-4 times a year with silicone spray.
Two times yearly or in the event rotating the antenna becomes difficult, normal
operation can be restored by lubricating the bearing surface between the rotating
gear housing and the base plate. Any silicone lubricant spray may be used.
Lubricate rubber quad ring on elevating shaft which is below worm gear with
silicone spray lubricant at least twice yearly. This will keep quad ring from
becoming brittle which could result in leaks down elevating shaft.
Refer to the manufacturer’s user guide for detailed information on lubricating the
antenna.
EXTERIOR TELEVISION (IF SO EQUIPPED)
The exterior television is located on the curbside of the unit. You can access the
television by opening the exterior cargo door to the stationary open position.
Refer to the individual component manufacturer’s information (located in the
Warranty Packet) for detailed operating instructions.
CAUTION
Make sure the television antenna is in the travel position (cranked down)
before moving the motor home. Failure to lower the antenna into the travel
position before traveling may damage the antenna.
