EVOi.net
28
TECHNICAL DATA
E V O i .net S p e c i f i c a t i o n s
Inputs: 2 channels, Max. level +20dB (7.5Vrms), 8k Ohms impedance, Electroni-
cally Balanced, XLR connectors, pin 2+
1 Dedicated JBL Measurement Microphone, XLR
Outputs: 4 Channels, Dedicated EVO Intelligent Speaker outputs, Electronically
Balanced, XLR connectors, pin 2+
Outputs 1 & 2 dedicated Main System outputs with Mono Sum capability
Outputs 3 & 4 dedicated Auxiliary System Outputs, with “Delay Set”
option and Mono Sum capability
Signal–to–Noise Ratio: >110dB, 22Hz – 22kHz
THD: <0.01%, 20Hz – 20kHz @+10dBu
Front Panel Controls: Auto EQ Setting, Delay Setting, Test Function, User EQ Select, User Anti
Feedback Control
Front Panel Indicators: Input signal monitoring, Speaker Status Self Diagnostics, System Locked,
Power On
Rear Panel Controls: Outputs 1 & 2 Mono Sum, outputs 3 & 4 Mono Sum, System Lock switch
Other Connectors: RS232 front panel, 2 x RJ45 rear panel
Frequency Response: 20Hz - 20kHz <+/-0.5dB
Power Requirements: 100-240 Volts 50/60Hz +/-10%
Measurement Mic: Dedicated EVO, electret type microphone with clip and hard storage case
Mic. Signal Cable: 30.5m (100ft) XLR Signal Cable
Dimensions: 19” Rack Mount (1 Unit) 1
3
/4” H x 19” W x 6
3
/4” (171mm) D
Weight 19” Rack Mount: 2.6Kg (5.7lbs)
