DISPLAY
Use the included 6m (19.7 ft) cable to connect the display unit to the MS-8’s main unit’s display connection.
Insert the cable’s straight connector into the main unit and the right-angle connector into the display.
NOTE: The display unit must be connected during setup but may be disconnected after setup and after
you’ve made any additional adjustments in the Audio Controls menu (see Audio Controls Menu, on page 36).
If the display unit is disconnected after setup and nal adjustment, you will not be able to make any additional
MS-8 adjustments, and the remote control will not function. See Main Menu, on page 35.
MICROPHONE
The included binaural microphone headset must be connected to the MS-8’s Mic connection during the
calibration/setup process. Once setup is complete, unplug the microphone headset and store it in a safe
place.
IMPORTANT: Do not use any other microphone with the MS-8.
REMOVE
FOR
SOFTWARE
UPDATE
Plug angled connector
into display
Plug straight connector
into main unit
Connect to mic input
C
ONNeCTiON
s
15
CONNECTIONS
MS-8
