System Spec
System Type: Self powered 15", three-way, bass-reflex
Maximum SPL Output: 135 db peak
Frequency Range (-10 dB):
Flat 41 Hz -19 kHz
Boost 40 Hz -19 kHz
Frequency Response (±3 dB):
Flat 53 Hz -18 kHz
Boost 50 Hz -18 kHz
Input Connectors: Balanced XLR / 1/4 inch combo jack with XLR loop through,
Input Impedance: 20K Ohms (balanced), 10K Ohms (unbalanced)
Signal indicators: Limit : Red LED indicates limiter active condition
Signal: Green LED indicates signal present
EQ: Presets for use in Main and Boost position
Dynamic Control (Input): dbx Type IV™ limiter circuit
Crossover Modes: DSP controlled. LF: 48 dB/Oct. filter slope High & Low Pass
HF: 36 dB/Oct. High Pass
Crossover Frequency: 460 Hz, 2.75 kHz
Amplifier
Design: Crown® Class D
Power Rating: 1500 W (3 x 500)
Speaker
LF Driver: 1 x JBL 265F-1, 380 mm (15 in) Differential Drive® dual voice-coil
and magnetic gap, neodymium woofer
MF Driver: 1 x JBL 195H, 165 mm (6.5 in) horn-loaded midrange transducer
HF Driver: 1 x JBL 2414H 25.4 mm (1 in) annular polymer diaphragm,
neodymium compression driver
Coverage Pattern: 90º x 50º nominal
Directivity Index (DI): 9.6 dB
Directivity Factor (Q): 9.1
Enclosure: Trapezoidal, 18 mm, plywood
Suspension/ Mounting: 36 mm pole socket, 8 x M10 Suspension Points and 1 x M10 Pull-
Back Point
Transport: Integrated handle with backing cup
Finish: Obsidian DuraFlex™ finish
Grille: Powder coated, Obsidian, 16 gauge perforated steel with
acoustically transparent black cloth backing.
Input Connectors: Balanced XLR / 1/4 inch combo jack with XLR loop through
Dimensions (H x W x D): 921 mm x 429 mm x 413 mm (36.29 in x 16.9 in x 16.27 in)
Net Weight: 27.2 kg (60 lb)
Gross Weight: 29.2 kg (64.5 lb)
PRX635
16
