SYSTEM SET UP - FULL RANGE MODELS
PRX600 Amplifier Input Configuration for
PRX612M, PRX615M, PRX625 and PRX635 Full-Range Models:
1
234 5
6
7
8
9
10
Features
1 - EQ BOOST / FLAT: When set in the “FLAT” position, frequency response is linear and unaltered. When
“Boost” is selected, internal equalization is applied to enhance low frequency and high
frequency response. “FLAT” will provide greater accuracy of reproduced music, higher
speech intelligibility and maximum overall level. “BOOST” is particularly useful at lower
levels to enhance the low and high frequencies of pre-recorded music. The feature
provides flexibility without the need to use an external equalizer. The following graph
shows the effect of the “BOOST” setting.
MAIN/MONITOR: Switching between “MAIN” and “MONITOR” optimizes the system for use as either a main
full-range system, or a stage monitor. (PRX612M and PRX615M only).
19
