· 8 ·
You will view the following
screens by pressing ◄ / ► to
switch between all functions and
settings.
Press «ENTER» to do battery
test.
Press «ENTER» to do system
test.
Press «ENTER» to do In-vehicle
test.
Press «ENTER» to print last re-
sult.
Press «ENTER» to change lan-
guage.
Press «ENTER» to start adjus-
ting brightness of the screen.
Press «ENTER» to edit customi-
zed info.
Press «ENTER» to see how
many times you tested in battery
/ system / in-vehicle test.
Press «ENTER» to start Date
& Time Setting. Then press ◄ /
► to adjust “Year”. Press «EN-
TER» to nish Year. Please fo-
llow previous step to nish Mon-
th, Day, Hour & Minute.
SYSTEM
ANALYZER
IN-VEHICLE
TEST
XX.XX V
LANGUAGE
SELECT
BRIGHTNESS
CUSTOMIZE
TEST
COUNTER
2018/02/05
13:25:00
BATTERY TEST:
2. Press the ◄ ► to select
REGULAR/STD or START/
STOP battery.
* REGULAR/STD BATTERY:
FLOODED, AGM FLAT PLATE, AGM SPIRAL, VRLA/
GEL
* START/STOP BATTERY:
AGM FLAT PLATE, EFB
1. Select BATTERY TEST.
Press «ENTER».
3. Press the ◄ ► key to select
the battery type:
5. Press the ◄ ► key to select
the battery rating: CCA/SAE,
EN, JIS, DIN, IEC, & CA/
MCA.
7. Press the ◄ ► key to input
the battery capacity.
CCA/SAE: 40~2000
EN: 40~1885
DIN: 25~1120
IEC: 30~1320
JIS: By Battery Type No.
CA/MCA: 50~2400
4. Press «ENTER» to conrm choice.
6. Press «ENTER» to conrm choice.
REGULAR/STD
START/STOP
BATTERY
TEST
XX.XX V
BATTERY
TYPE:
AGM FLAT
PLATE
8. Press the ◄ ► key to con-
rm temperature.
ABOVE
32°F/0°C?
YES/NO
printer.
PAPER REPLACEMENT:
A. Open the clear cover.
B. Insert replaced paper roll into the paper feeding for
auto running the paper into the printer.
C. Pull the paper slowly and straightly from the paper
roll in the chamber.
MAIN MENU:
*Return Feature: Before the test is started, the
user can always return to the previous setting
page by pressing <<ENTER>> for 2 seconds.
SURFACE CHARGE NOTICE:
The battery will hold a surface charge if the engine has
been running or after the battery has been charged.
The tester may prompt you to remove the surface char-
ge.
A. Follow the instructions indicating when to turn the
headlights on and o or apply a load into the ba-
ttery.
IN VEHICLE:
9. Press <<Enter>> to begin the test.
SURFACE CHAR-
GE IN VEHICLE?
YES
TURN HEADLI-
GHTS ON FOR 15
SECS
BATTERY TEST
XX.XX V
SYSTEM TEST
XX.XX V
PRINT LAST
RESULT
SELECT
RATING:
CCA/SAE
SELECT CAPA-
CITY:
560CCA/SAE
