PARTS LIST - PUMP
MODEL 150
NO. DESCRIPTION QTY.
201 Seal Washer 1
202 Pump Cylinder 1
203 Dust Ring 1
204 Y-Seal 1
205 Pump Piston 1
206 Spring 1
207 Spring Cap 1
208 Retaining Ring 1
209 Joint Plate 2
210 Pin 1
211 Pump Body 1
212 Elastic Pin 1
213 Spring 1
214 Strike Pin 1
215 Seal Washer 1
216 Axle Sleave 1
217 O-Ring 2
218 Nut 1
219 Screw 1
220 Lever Plate 1
221 Nut 1
222 Elastic Washer 1
223 Washer 1
224 Bolt with Hole 1
225 Bolt with Hole 1
226 Nut 1
227 Plug 1
228 O-Ring 1
229 Adjusting Bolt 1
NO. DESCRIPTION QTY.
230 Spring 1
231 Safety valve spindle
232 Steel Ball 1
233 O-Ring 1
234 Pumping valve seat 1
235 Pumping valve spindle 1
236 Spring 1
237 Seal Washer 1
238 O-Ring 1
239 Seal Washer 1
240 Cylinder 1
241 Housing 1
242 Bolt 1
243 Seal Washer 1
244 Retaining Ring 1
245 Washer 1
246 O-Ring 1
247 Cup Packing 1
248 Piston 1
249 O-Ring 1
250 Piston Rod 1
251 Seal Washer 1
252 Cylinder Cap 1
253 O-Ring 1
254 Dust Ring 1
255 Plug 1
256 Liquid Throttle Sheath 1
257 Bolt 1
