01 - Machine
09 - Description
15 - Service Point Locations
01 - 28 9813/5150-2 01 - 28
(For: 225 [T3 GE0], 225 [T4F GE0], 225T [T3 GE0], 225T [T4F GE0], 260 [T3 GE0], 260
[T4F GE0], 260T [T3 GE0], 260T [T4F GE0], 280 [T3 GE0], 280 [T4F GE0], 300 [T3 GE0],
300 [T4F GE0], 300T [T3 GE0], 300T [T4F GE0], 320T [T3 GE0], 320T [T4F GE0], 330 [T3
GE0], 330 [T4F GE0])
Wheeled Machines
Figure 12.
A Coolant expansion bottle B Fuel sedimenter
C Air intake D Engine oil filler cap
E Engine oil dipstick F Hydraulic oil level indicator, Hydraulic oil filler
cap
G Battery isolator H Battery
J Radiator K Radiator cap
L Window washer fluid bottle M Chain case oil port
To Next Page
