jcb 270T - Page 32

01 - Machine
09 - Description
12 - Main Component Locations
01 - 26 9813/7450-2 01 - 26
Figure 11.
4
3
6
8
7
1
2
5
9
1 ROPS/FOPS cab 2 Fuel tank filler point
3 Lift arm/boom 4 Front working lights
5 Quickhitch 6 Rubber tracks
7 Engine top cover 8 Wheels/tyres
9 Exhaust
