REPLACE THE CARBON
BRUSH AS FOLLOWS: (See
8
&
9
)
Unscrew the brush cap (17),
remove the carbon brush (15), if the
carbon has worn down to 6mm it
should be replaced. Always replace
both brushes at the same time, insert
the new brush and replace the brush
cap. Check that the tool is working.
Before use, allow it to run for a few
minutes to enable the brushes to
settle.
9
15
17
8
