03 - Attachments and Options
27 - Bucket
90 - Teeth
03 - 16 9813/2650-3 03 - 16
Remove and Install
Standard Teeth
Remove
1. Make the machine safe. Refer to (PIL 01-03).
2. Put the bucket flat on level ground.
3. Stop the engine.
4. Remove the ignition key.
5. Discharge the hydraulic pressure. Refer to (PIL
30-00).
6. Remove the nut and bolt.
7. Remove the relevant tooth.
Figure 18.
A Tooth
B Nut and bolt
Installation
1. Put the tooth in position.
2. Install the nuts and bolts to secure the tooth in
position.
To Next Page
