DUAL TOP — IF EQUIPPED
If your vehicle is equipped with a Dual Top, you must
remove one of the tops from the vehicle. The soft top
was installed at the factory for shipping purposes only.
The soft top and the hard top are to be used indepen-
dently. Removal is mandatory to prevent any possible
wear and tear on the soft top, should both tops remain on
the vehicle at the same time.
Removing The Soft Top
1. Locate and remove the 2 boxes that contain the
following items:
•
right and left door frames
•
door frame attachment knobs (4)
•
right and left quarter windows
•
rear tailgate window
2. Remove the hard top. Refer to “Hard Top Removal” in
this section.
3. Remove the soft top bow assembly pivot bracket
screws (2 per side) using a #30 Torx威 head driver.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73
3
