Cavity Cartridge
Fuse
Mini
Fuse
Description
17 10 Amp
Red
IOD Feed Mod-Wcm
18 40 Amp
Green
ASD Relay Contact
PWR Feed
19 20 Amp
Yellow
PWR Amp 1 & Amp
2 Feed
20 15 Amp
Lt. Blue
IOD Feed Radio
21 10 Amp
Red
IOD Feed Intrus
Mod/Siren
22 10 Amp
Red
IGN RUN Heat/AC/
Compass Sensor
23 15 Amp
Lt. Blue
ENG ASD Relay Feed
3
24 15 Amp
Lt. Blue
Power Sunroof Feed
Cavity Cartridge
Fuse
Mini
Fuse
Description
25 10 Amp
Red
Heated Mirror
26 15 Amp
Lt. Blue
ENG ASD Relay Feed
2
27 10 Amp
Red
IGN RUN Only ORC
Feed
28 10 Amp
Red
IGN RUN ORC/OCM
Feed
29 Hot Car (No Fuse Re-
quired)
30 20 Amp
Yellow
Heated Seats
31 10 Amp
Red
Headlamp Washer
Relay Control
32 30 Amp
Pink
ENG ASD Control
Feed 1
