Jeep Compass 2014 - Page 513

Cavity Cartridge
Fuse
Mini-Fuse Descrip-
tion
14 10 Amp
Red
Instrument
Cluster
15 40 Amp
Green
Radiator
Fan
16 15 Amp Lt
Blue
Dome
Lamp/
Sunroof/
Rear Wiper
Motor
17 10 Amp
Red
Wireless
Control
Module
18 40 Amp
Green
Auto Shut-
down Re-
lay
Cavity Cartridge
Fuse
Mini-Fuse Descrip-
tion
19 20 Amp
Yellow
Radio Am-
plifiers
20 15 Amp Lt
Blue
Radio
21 10 Amp
Red
Intrusion
Module/
Siren – If
Equipped
22 10 Amp
Red
Heating,
AC/
Compass
23 15 Amp Lt
Blue
Auto Shut-
down Re-
lay
7
MAINTAINING YOUR VEHICLE 511
