To turn the LaneSense system off, push the
LaneSense button once to turn the system off
(LED turns on).
NOTE:
The LaneSense system will retain the last sys-
tem state on or off from the last ignition cycle
when the ignition is changed to the ON/RUN
position.
LaneSense Warning Message
The LaneSense system will indicate the current
lane drift condition through the instrument clus-
ter display.
Base Instrument Cluster Display — If
Equipped
When the LaneSense system is on; the lane
lines are gray when both of the lane boundaries
have not been detected and the LaneSense
telltale
is solid white.
Left Lane Departure — Only Left Lane De-
tected
• When the LaneSense system is on, the Lane-
Sense telltale
is solid white when only the
left lane marking has been detected and the
system is ready to provide visual warnings in
the instrument cluster display if an uninten-
tional lane departure occurs.
• When the LaneSense system senses the
lane has been approached and is in a lane
departure situation, the left thick lane line
flashes from white to gray, the left thin line
remains solid white and the LaneSense tell-
tale
changes from solid white to flashing
yellow.
NOTE:
The LaneSense system operates with the simi-
lar behavior for a right lane departure when only
the right lane marking has been detected.
Left Lane Departure — Both Lanes Detected
• When the LaneSense system is on, the lane
lines turn from gray to white to indicate that
both of the lane markings have been de-
tected. The LaneSense telltale
is solid
green when both lane markings have been
detected and the system is “armed” to pro-
vide visual warnings in the instrument cluster
display and a torque warning in the steering
wheel if an unintentional lane departure oc-
curs.
• When the LaneSense system senses a lane
drift situation, the left thick lane line and the
left thin line turn solid white. The LaneSense
telltale
changes from solid green to solid
yellow. At this time torque is applied to the
steering wheel in the opposite direction of the
lane boundary.
• For example: if approaching the left side of
the lane the steering wheel will turn to the
right.
System On (Gray Lines/White Telltale )
Lane Approached (Flashing White To Gray
Thick Line/Flashing Yellow Telltale
)
Lanes Sensed (White Lines/Green Telltale )
197
