3. There is no fuel filler cap. A flapper door
inside the pipe seals the system.
4. Insert the fuel nozzle fully into the filler pipe;
the nozzle opens and holds the flapper door
while refueling.
5. Fill the vehicle with fuel, and when the fuel
nozzle “clicks” or shuts off, the fuel tank is
full.
6. Wait ten seconds before removing the fuel
nozzle to allow fuel to drain from nozzle.
7. Remove the fuel nozzle and close the fuel
door.
Emergency Gas Can Refueling
Most gas cans will not open the flapper door. A
funnel is provided to open the flapper door to
allow emergency refueling with a gas can.
1. Retrieve funnel from the spare tire storage
area.
2. Insert funnel into same filler pipe opening as
the fuel nozzle.
3. Ensure funnel is inserted fully to hold flapper
door open.
4. Pour fuel into funnel opening.
5. Remove funnel from filler pipe, clean off prior
to putting back in the spare tire storage area.
NOTE:
• In certain cold conditions, ice may prevent the
fuel door from opening. If this occurs, lightly
push on the fuel door to break the ice buildup
and re-release the fuel door using the inside
release button. Do not pry on the door.
• When the fuel nozzle “clicks” or shuts off, the
fuel tank is full.
WARNING!
• Never have any smoking materials lit in or
near the vehicle when the gas cap is
removed or the tank is being filled.
• Never add fuel when the engine is running.
This is in violation of most state fire regu-
lations and may cause the MIL to turn on.
• A fire may result if gasoline is pumped into
a portable container that is inside of a
vehicle. You could be burned.Always place
gas containers on the ground while filling.
Emergency Fuel Filler Door Release
If you are unable to open the fuel filler door, use
the fuel filler door emergency release.
1. Open the liftgate.
2. Remove package tray if equipped.
3. Remove access door located on right interior
trim panel for release cable with the tip of
your key.
Fuel Funnel
202
