Cargo Load Floor
The cargo load floor system has a load capacity
of 400 lbs (181 kg).
Cargo Load Floor Positions
The cargo load floor can be adjusted to three
different levels to create more space in the
cargo area. These positions are: upper, center,
and lower.
NOTE:
The lower position is not available in vehicles
equipped with either a compact spare tire, or a
full size spare tire. The center position is not
available in vehicles equipped with a full size
spare tire.
To change the level of the load floor, pull upward
on the load floor handle, pull the floor outward,
and place the back of the floor into the desired
position. Lower the front of the floor into place.
Raising The Load Floor
To raise the load floor for access of the Tire
Service Kit, or spare tire (if equipped), pull
upward on the load floor handle.
Do not raise the floor beyond the point of
resistance. In vehicles equipped with a power
liftgate, forcing the floor upward can damage the
floor and vehicle’s trim panel.
To fully raise the load floor, pull upward on the
floor handle, pull the floor outward, then position
the floor upright with the bottom fitting on top of
the floor positioning brackets. Push the top of
the floor down firmly to secure it in this position.
Rear Shelf Removal Label Cargo Load Floor Positions
1 — Upper Position
2 — Center Position
3 — Lower Position
Raised Load Floor — (Power Liftgate)
1 — Raised Load Floor
2 — Raised Floor Maximum Height
Fully Raised Load Floor Position
