Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
F14 – – 7.5 Amp Brown Diesel Crankcase Heater
(*)
F15 40 Amp Orange – – Brake Control Module Pump
(*)
F16 – – 10 Amp Red Engine Control Module Power,
Automatic Transmission
(*)
F17 – – 10 Amp Red Engine Secondary Loads
(*)
F18 – – 20 Amp Yellow 12V Rear Cargo Outlet Ignition Powered
F19 – – 7.5 Amp Brown Air Conditioner Compressor
F20 – – 20 Amp Yellow Cigar Lighter
F21 – – 20 Amp Yellow Fuel Pump
(*)
F22 – – 20 Amp Yellow –
Gas Engine
15 Amp Blue –
Diesel Engine
Gas - Ign Coil/Fuel Injector Diesel-
Diesel Components
(*)
F23 – – 30 Amp Green Window Heater Grid
F24 – – 15 Amp Blue Electronic Unit Supply
Automatic Transmission
(*)
F30 – – 20 Amp Yellow
(Customer Selectable,
Move From F18)
12V Rear Cargo Outlet
Constant Battery Powered
IN CASE OF EMERGENCY
202
