Jegs Torch User Manual

Sway Bar Assembly Continued
555-44776
M3x18mm BH
555-44863
6x8x0.2mm Washer
(Shims may vary.)
555-44776
M3x18mm BH
555-44863
6x8x0.2mm Washer
(Shims may vary.)
555-44776
M3x18mm BH
555-44776
M3x18mm BH
Front
B
B
A
A
Use Threadlocker
Set Screw Do not
overtighten
When installing the Tension Bar, make sure
to push it all the way in and tighten it with an
M3x5mm screw. Refer to the diagram.
555-44786
M3x5mm BH
555-44798
M4x3mm Set Screw
555-44672
1.8mm Tension Bar
555-44861
1.6/2.08mm Tension Bar
(Optional)
25
