REFRIGERATOR DOOR PARTS
16
For Model: JS48PPDUDB01
(Stainless Steel)
W10242818
Illus. Part
No. No. DESCRIPTION
1
W10193491
Refrigerator
Door Panel
(Includes
Item #9)
3 2266854 Hinge Assembly,
Top
4 2316804 Spacer−Door,
Top & Bottom
5 489282 Screw
6 2302878 Hinge Assembly,
Bottom
7 2222797 Rail, Lid
8 2222983 Gaasket, Utility
Bin
9 2222812 Door Gasket,
Magnetic
10 Skin, Door
W10144970
Stainless Steel
11 Handle, Door
12859108 Stainless Steel
12 Spacer, Door−Skin
(Handle Side)
2309060 For Stainless
Steel Model
13
W10153450
Stud, Handle
14 488568 Screw
15 Screw, 8−15 x .500
8281250 Stainless Steel
16 2005433 Spacer, Door−Skin
(Top)
17 308544 Screw, Handle
18
W10142296
Spacer, Door−Skin
(Hinge Side)
19 2004935 Spacer, Door−Skin
(Bottom)
20 2005327 Filler, Door
21 End Cap
2222919 Right Side
2222920 Left Side
22
W10127710
Plate, Door−Handle
25 2222923 Bin, Utility
Center
26 2257617 Door, Utility Bin
27 2222774 Bin, Door (3)
30 2222771 Bin, Door
To Next Page
