LOWER UNIT AND TUBE PARTS
24
For Model: JS48PPDUDB01
(Stainless Steel)
W10242818
Illus. Part
No. No. DESCRIPTION
1 W10160981 Bracket Assembly,
Air Return
2 486194 Screw
3
W10157752 Bracket
4 2309076 Suction Tube
5 2309070 Tube, Connect
(Drier/Restrictor)
6 2320615 Drain Pan Assy.
7
W10151288 Cover, Wiring
8
W10153595 Cover, Box
9
W10121374 Tube, Discharge
10 2188820 Thermistor
11
W10205102 Evaporator
12
W10140162 Heater, Defrost
13 1113048 Clamp, Heater (2)
14
W10139908 Cover Seal,
Evaporator Tubes
15 2220832 Gasket, Evaporator
16 2155774 Wire Tie
17
W10169509 Clip, Heat
Exchanger
18 2320554 Support, Drain Pan
19 9791833 Clip
