ICEMAKER PARTS
26
For Model: JS48PPDUDB01
(Stainless Steel)
W10242818
Illus. Part
No. No. DESCRIPTION
2 2320601 Shield, Valve
3 2310191 Wire Assembly,
Icemaker
6
W10174395
Tube, Filter Inlet
7 2320658 Water Tube
8 2302758 Seal Gasket
9 2317912 Tube, Filter
Outlet
10
W10159842
Valve, Solenoid
12 2221070 Clamp, Tube
13 2320559 Support, Valve
14 2198641 Bracket, Icemaker
Cover
15 2208136 Clamp, Nylon
Valve
17 2302756 Tube, Water Inlet
18 2257538 Cover
19 488500 Screw
20
W10122527
Mold & Heater
(Also Order
542638 Silicone
Grease)
21 Motor, (Not
Serviceable Order
Item 32)
22 2304969 Cup−Water Fill
23 627843 Ejector
24 2198598 Ice Striper
25 2194712 Support
26 2315522 Retainer
Thermostat (2)
27 628397 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29
W10139199
Wire Assembly
31 2221232 Cover, Icemaker
32 626691 Module Assembly
(Includes Items
21 & 33)
33 489276 Screw (2)
34 489464 Screw
35 486194 Screw
36 2252228 Bracket, Icemaker
Mounting
100
W10190968
Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
8537055 Cleaner,
Stainless Steel
W10151246
Ice Container
Assembly
