Device description

LDM52 OEM, Release 003, Revision 000

4.4 Laser beam image

The laser beam of the LDM52 OEM has a divergence of 0.13 mrad x 0.17 mrad (width x height).

The diameter of the laser spot on the exit lens measures 4 mm.

The table below shows the size of the laser spot in dependence on the distance. The laser spot

has an elliptical shape.

Distance

Laser spot width

Laser spot height

1 m

5 mm

5 m

3 mm

10 m

4 mm

5 mm

50 m

6 mm

7 mm

100 m

26 mm

34 mm

200 m

52 mm

68 mm

The above-mentioned laser spot holds approx. 50 % of the entire laser energy. An aura with less

energy forms around that spot.
