Page #30 background image
Parameter setup and measuring operation
LDM52 OEM, Release 003, Revision 000
29
For parameterizing of switching outputs see chapter 6.6
6.4.14 SE – Error Mode
Parameterizes the behavior x of switching outputs Q1, Q2, Q3, of the analog output QA and an
external SSI Interface in case of faulty measurements as well was the condition upon execution
of an individual distance measurement
Query:
SE
Set:
SEx
Range of parameter x:
0, 1 or 2
Standard:
1
x
Q1, Q2, Q3
QA
SSI
z = 0
z = 1
24 bit
25 bit
0
Last value
Last value
Last value
Last value
MSB High
1
High
Low
3 mA
000000
MSB High
2
Low
High
21 mA
999999
MSB High
Output in CMOS level:
low = 0 U < 0,8 V
high = 1 U > 2,0 V
The LDM52 OEM does not check the set error mode for plausibility!
Bit 7 6 5 4 3 2 1 0
0 0 0 0 0 1 0 1
MSB Q1 Q2 Q3
= 0 on off on
