6.8.3 TRO – Trigger output
The parametrization of trigger output will be set with command TRO.
x edge parameterized the edge of trigger signal
0 rising edge (from LOW to HIGH)
1 falling edge (from HIGH to LOW)
2 every edge
y delay parameterized the time (delay) up to the measurement in milliseconds msec
Query:
TRO
Set:
TRO x y
Value range parameter x:
0, 1, 2
Value range parameter y:
0 to max 60 000 msec (equal to 1 minute)
active: from 1 msec upward
disabled: 0 msec
Standard:
0 0
Output: Trigger (output) [TRO]: 0, 0
Voltage levels for trigger signals OUT (load resistance 30 kOhm):
Low-Pegel 0 V
High-Pegel > 2.9 V
Hysterese 0.1 V
