Jenoptik LDM51 Series User Manual

Technical Data
LDM52 OEM, Release 003, Revision 000
51
9 Technical Data
Measurement properties
Measurement principle
Pulse reflection mixing method
Measured parameter
Distances
Measuring range
1
Total
Onto Oralite 5200 target board
Onto Oralite special target board
Onto natural surfaces, 80% remission
Onto natural surfaces, 6% remission
0.15 m … 200 m
50 m … 200 m
0.15 m … 100 m
0.15 m … 100 m
0.15 m … 85 m
Accuracy, absolute
1
< + 3.9 mm
Repeatability
+ 0.6 mm
Resolution of measured values
0.1 mm
Measuring period, minimum
10 ms
Laser
Laser classification
Laser class 2, EN 60825-1:2014
Wavelength
655 nm (red)
Divergence
< 0.2 mrad
Laser spot in 10 m
4 mm x 5 mm
Electric connection conditions
Supply voltage
5 + 0,5 V DC
Power consumption
< 2,5 W
Interface/ connections
Connections on device
16-pin connector (male), FH12-10S-0.5SH(55)
Serial interfaces
RS232, CMOS level 3,3 V
Switching output
3x, Pegel 0 V … 3,3 V DC
Analog output
4 mA … 20 mA
Error handling at 3 mA / 21 mA
Total output error at 20 mA: + 0.15 % at a temperature of
+25°C
Trigger, input + output
1x IN/ OUT, 0 V … 3.3 V DC
