Overview
LDM52 OEM, Release 003, Revision 000
1 Overview
1.1 Symbols and references
Reference (to a text passage or illustration)
1.2 Warning signs
The sign Caution warns against dangers to health which may occur if this advice is not ob-
served
The sign Attention warns against possible damage to the device
The sign Information points to important information.
This sign indicates that special environmental protection guidelines must be observed when
disposing of the device.
1.3 General information
The laser distance meters of the LDM51 series have been designed for application in industrial
facilities.
Within the measuring range of 15 cm to 200 m the sensors work with a high accuracy of up to +
1 mm and at a variably adjustable measuring frequency of maximally 100 Hz.
Due to the excellent optical measuring performance of the LDM52 OEM, the sensors can be
used both indoors and outdoors, even in case of a high percentage of constant light.
When great distances of more than 50 m need to be measured, the sensor can be used in com-
bination with a reflector.
