Part Identification
Back View
E gn l hsi
8
2
4. HDMI 1 / HDMI 2 INPUT
3. USB Port
5. COMPONENT INPUT
6. AV IN ( VIDEO and AUDIO)
7. SPDIF OUTPUT
8. RF IN
2. AUDIO (L/R) OUT
1. DC 12V
2
1
3 4
4
5
6 7 8
JTV2815DC
7
