78
ENGINE
7. Check
Main driven gear stopper
Scrape, wear, damage
Barbing or replace
Clutch hub
Scrape, wear, damage Replace
8. Check
Steel ball
Push rod 1
Pressure plate
Wear, damage Replace
4. Check
Clutch lining
Damage
Replace clutch lining completely
5. Measurement
Clutch warp
Out of specification
Replace clutch lining com-
pletely
Use plate and caliper gauge
6. Measurement
Clutch spring length
Damage Replace clutch spring completely
Friction limit value:
less than 0.05mm
Clutch spring length: 33.0mm
Limit: 31.0mm
