27
Jiffy
®
J-4000 Wiring Instructions
1. Positive black (1) (brown for 230 volt units) to A on switch.
2.
Neutral white to (2) brown fuse wire (4) (blue for 230 volt units).
3. Green ground wire (3) to grounding mount on housing.
4. Brown fuse (4) wire to B on switch.
5. Blue wire (5) from top of preheat thermostat (L170) to #1 on
switch.
6. White wire (6) from left side of element to #4 on switch.
7. Red wire (7) from top of steam thermostat (L-220) to (2)
on switch.
8. Long yellow wire (8) from bottom of preheat thermostat to right
side of element.
9. Short yellow wire (9) from right side of element to bottom of
steam (L-220) thermostat.
10. White wire (10) from light to left side of element.
11. Medium length yellow wire (11) from light to right side of
element.
Please note, the switch terminal numbers and the switch
terminal letters are marked on the actual switch.
J-4000
Questions?
When calling our technical support line
@ 1-800-525-4339
or e-mail us at
jsinfo@jiffysteamer.com
Please have your
model and serial number available.
