Jiffy
®
J-1 and J-2 Wiring Diagram
1. Insert cord set (1) into housing and connect black positive wire (2) from
cord set to terminal number 5 on the switch.
2. Secure with grounding screw ground wire from cord set to the ground
location on the housing (3).
3. Connect blue wire (4) from the right side of brass heating element (5) to
right side of the L-290 thermostat (6).
4. Insert brass heating element unit into housing. Hand tighten the brass nuts
(7) on the water line to the element and to the 90 degree fitting from the
cup. Tighten 2 mounting screws (8) at the base of heating element. Now,
use a 5/8” wrench to securely tighten the brass nuts on the water line to the
element and to the 90 degree fitting from the cup. Heating unit may be
loosened and adjusted f
or a better f
it if necessar
y.
5.
Connect w
hite wire (9) from the left side of the heater unit to terminal
n
umber 6 on s
witc
h.
6.
Connect y
ello
w wir
e (10) from the left side of the thermostat to terminal
n
umber 3 on the s
witc
h.
7.
Connect w
hite neutr
al wir
e (11) fr
om cor
d set bundle to orange fusible link
with plastic connector (12).
8.
Connect other end of or
ang
e fusib
le link to ter
minal n
umber 2 on the
switch.
9. Set steamer upright and place black plastic strain relief (13) approximately
4 1/2” from end of cord set and insert into housing using pliers.
10. Secure bottom plate with four screws.
11. To avoid leakage, be sure to tighten hose (or hat nozzle) with wrench
before using steamer.
Before attempting any repair on a Jiffy Steamer product, make sure that it
is unplug
g
ed from the outlet. If you have any questions, please contact our
repair department at 1-800-525-4339 between 7:30 AM - 4:00 PM Central
Standard Time.
Please note switch terminal 2, 3, 5 and 6 indicated on the enlarged switch
dia
g
r
am ar
e mar
ked on the actual switch. Jiffy® Steamers manufactured
before May 2000 are not marked with the terminal switch numbers.
Number
s in par
enthesis r
ef
er to the dr
a
wing on on the r
ight.
