Page #7 background imageLoading...
Page #7 background image
7
Esteam
®
Parts Diagram Key
ESTEAM
®
Should you ever need replacement parts for your Jiffy
®
Steamer, you may purchase
them separately. Use this handy diagram and parts list to identify any part you may
need. Please include model and serial number when ordering.
Jiffy Steamer
Key# Part # Part Description
1 0653 Esteam 120 Volt 600 Watt Heater
with Gaskets and Nut
0655 Esteam 230 Volt 625 Watt Heater
with Gaskets and Nut
1a. Esteam Heater
(Sold with Item #0653 or #0655 as a Kit)
1b. Gasket for Esteam Heater
(Sold with Item #0653 or #0655 as a Kit)
1c. Nut for Esteam Heater
(Sold with Item #0653 or #0655 as a Kit)
2 0661 Red Inside O-Ring
3 0662 Black Outside O-Ring
4 0669 Esteam Water Tank
5 0640 Esteam 36 T-L263 Thermostat
6 0643 Fusible Link Clamp
7 0644 Fusible Link Clamp Screw
8 0641 Fusible Link Wire with Insulated Lug (Orange)
9 0681 Red Wire with Insulated Lugs
10 0645 Pilot Light with Wiring Harness
for 120 Volt Electrical Systems
0646 Pilot Light with Wiring Harness
for 230 Volt Electrical Systems
11 0647 Cord set (18/2 gauge)
12 0665 Right Case Half
13 0666 Left Case Half
14 0667 Four (4) Screws for Esteam Outer Case Halves
15 0663 Complete Steam Cap with Face Plate
ACCESSORIES
0619 Voltage Converter for Travel
0899 Liquid Cleaner - 3 Ten (10) Ounce
Bottles per Package*
*Not Available for Export.
ESTEAM Steam Caps with Face Plates and Case Halves are Available in Black or Pink.
Please specify color when ordering.
If you donʼt see the part you need, please contact us.
