JK Audio AutoHybrid User Manual

8
Technical Information
Input Impedance / Level
Balanced Female XLR: 1k ohms / 500 mV RMS; -4 dBu nom.; +6 dBu max
Insertion Loss:
11dB Send XLR to Phone Line
Maximum transmit level at Phone Line -3 dBu
Output
Balanced Male XLR: 600 ohms / 200 mV RMS; -12 dBu nom.
Screw Terminals
O󰀨-Hook Control: +5 VDC momentary
Release Control: +5 VDC momentary
OH LED Signal: Pulled to ground on OH
CPC Disconnect: 300 ms minimum
MISC
Phone Line Connector: RJ11C
Isolation: 1500 VAC
Ringer: 0.8B REN
Size: 4” x 5” x 1.5” (10.5 x 13 x 4 cm)
Weight: 12 oz (340 g)
