JLG SMART SYSTEM 1532E User Manual

SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).
3120442 – JLG Sizzor – 1-11
Table 1-5. JLG SMART System™ Flash Codes - (Machines equipped with1600258 controller)
Code Description
1-1 Idle time-out
2-1 EMS inputs (both together, or neither).
2-2 Platform (digital) inputs (includes high drive >
10 seconds).
2-3 Ground (digital) inputs.
2-4 Steering (digital) inputs.
2-5 Cut-out input (not a fault but indication).
2-7 Accelerator (analog) input.
2-8 Arm guards or platform descent delay system
cut-out.(European [CE Specification]
Machines Only)
3-1 Line contactor open circuit or welded.
3-3 Line contactor (or other) driver short circuit
(or tripped).
4-2 Temperature cut back.
4-4 Battery supply voltage out of range.
9-1 Watchdog reset.
9-2 EEprom fault.
9-3 Mux stream not being updated.
9-6 Point A short circuit.
9-7 Point A open circuit.
9-8 Motor open circuit.
9-9 Power circuit failure (driver short circuit, bat/
cap < 15V).
