SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).
1-4 – JLG Sizzor – 3120442
Table 1-1. Machine Personality Settings - (Machines equipped with a 1600258 controller).
PERSONALITY MIN MAX
DRIVE-ACCEL
0.5 SEC
5.0 SEC
DRIVE-DECEL
0 SEC
5.0 SEC
LIFT-ACCEL
0.5 SEC
5.0 SEC
LIFT-DECEL
0.5 SEC
1.5 SEC
DECK-ACCEL
0.5 SEC
5.0 SEC
DECK-DECEL
0 SEC
5.0 SEC
DRIVE-CREEP
1%
25%
LIFT-CREEP
1%
25%
DECK-CREEP
1%
25%
STEER-ONLY-CREEP
1%
35% (see note one)
STEER-EXTRA-CREEP
0%
35%
DRIVE-FDW AND REV SPEED
50%
100% - ALL MODELS W / WHITE DRIVE MOTORS
DRIVE-FDW AND REV SPEED
50%
100% - MODEL 2033 W / EATON DRIVE MOTORS
DRIVE-FDW AND REV SPEED
50%
80% - MODELS 1532 & 1932 W / EATON DRIVE MOTORS
LIFT-UP-MAXSPEED
50%
100%
LIFT-DOWN-MAXSPEED
30
100% (see notes 2 and 3)
DECK-IN-MAXSPEED
0
100%
DECK-OUT-MAXSPEED
0
100%
GROUNDSPEED-UP
0
100%
GROUNDSPEED-DOWN
0
100% (see notes 2 and 3)
GROUNDSPEED-DECK IN
0
100%
GROUNDSPEED-DECK OUT
0
100%
IDLE-TIME-OUT
0 MIN 30 MIN
