SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).
1-8 – JLG Sizzor – 3120442
NOTE: The following information is to be used when working with the MACHINE SETUP menu. When configuring the E Series
scissor lift, the machine configuration must be completed before any personality settings can be changed. Changing the
personality settings first and then changing the model number of the machine configuration will cause the personality
settings to return to default values.
Table 1-4. Machine Configuration Programming Information (Machines equipped with 1600258 controller)
Configuration Digit Number Description
Default Setting
Before
Programming
1
(MODEL NUMBER)
1
2
3
4
5
6
MODEL 1532E
MODEL 1932E
MODEL 2033E
MODEL 2046E
MODEL 2646E
MODEL 2658E
3
2
(TILT SWITCH)
0
1
2
3
4
No tilt switch installed.
5 tilt switch for North American machines. — This digit will allow the SMART Sys-
tem™ to indicate when the machine is more than 5 degrees out of level by lighting the
light in the platform. If the machine is elevated and tilted, the SMART System™ will
also sound the platform alarm continuously. No functions are cut back or cut out.
2 tilt switch for European machines. — This digit will allow the SMART System™ to
indicate when the machine is more than 2 degrees out of level by lighting the light in
the platform. If the machine is elevated and tilted, the SMART System™ will also
sound the platform alarm continuously. No functions are cut back or cut out.
2 tilt switch for Australian machines. — This digit will allow the SMART System™ to
indicate when the machine is more than 2 degrees out of level by lighting the light in
the platform. If the machine is elevated and tilted, the SMART System™ will also
sound the platform alarm continuously and the LIFT UP and DRIVE functions are cut
out.
5 tilt switch for Latin American and Japanese machines.— This digit will allow the
SMART System™ to indicate when the machine is more than 5 degrees out of level by
lighting the light in the platform. If the machine is elevated and tilted, the SMART Sys-
tem™ will also sound the platform alarm continuously and the LIFT UP and DRIVE
functions are cut out.
0
3
(POWER DECK)
0
1
No power deck installed.
Machine equipped with power deck.
0
