SECTION 1 - JLG SMART SYSTEM ™ ANALYZER KIT INSTRUCTIONS (1600258 CONTROLLER).
1-2 – JLG Sizzor – 3120442
To use the hand held analyzer: (1600258 Controller).
1. Connect the four pin end of the cable, supplied with the analyzer, to the top connection of the motor controller and
connect the remaining end of the cable to the analyzer. NOTE: The cable has a four pin connector at each end of the
cable; the cable cannot connect backwards.
2. Power up the SMART System™ by turning the lower key to the platform position and pulling both emergency stop but-
tons on.
The screen of the analyzer will look like the following:
ASPC MENU:
ACCESS LEVEL 3
Using the RIGHT and LEFT arrow keys, you can scroll throughout the top level menu items, which are:
ACCESS LEVEL
DIAGNOSTICS
PERSONALITIES
MACHINE SETUP
MACHINE DIGITS
Pressing ENTER at any of the above menu items takes you to the menu in that item. In some cases, such as ACCESS
LEVEL, the next level is the parameter or information to be changed. Please note that MACHINE DIGITS can only be viewed
and changed at access level 1. As an example of the next set of menu items, the following are the items under the PERSON-
ALITIES menu:
PLATFORM
GROUND
Under these items are the actual personalities that can be viewed or edited. To see what these personalities are, refer to the
organizational chart in figure 1-1.
The following is an example of how to view and change the DRIVE CREEP personality. This example assumes that the ana-
lyzer has been connected to the machine and the SMART System™ has been powered up.
1. Press the ENTER key when the screen shows the menu ACCESS LEVEL 3.
2. At the CODE prompt, enter 33271. To do this follow the steps below:
a. The flashing cursor should be at the first digit. Use the UP arrow key to increase the number to 3.
b. Use the RIGHT arrow key to scroll to the next digit and repeat step a.
c. Repeat the process until the new code is showing and then press ENTER. If a digit is missed, use the LEFT arrow
key to back up. If you pass the number desired to be entered at a digit, use the DOWN arrow key to decrease the
value.
3. Use the RIGHT arrow key to scroll to the PERSONALITIES menu item and push ENTER.
4. Use the LEFT or RIGHT arrow keys to scroll to the DRIVE CREEP personality.
5. Use the UP and DOWN arrow keys to change the value of the personality. The value is now changed.
6. To view something in DIAGNOSTICS, use the ESC key to back out of the PERSONALITY menu and use the same pro-
cedure to get there.
NOTE: Password 33271 will take you to access level 1, which will permit you to change all machine personality settings. There
are some settings that JLG strongly recommends that you not change, and these settings will be so noted. Changing
these settings may adversely affect the performance of your machine. All parameters accessible using the PC/laptop
computer with the system software are accessible using the analyzer.
