Johnson Controls tyco TY-B Series User Manual

TFP680
Page 3 of 16
Model
K-Factor
Response
Type
Temperature
Rating
Bulb
Liquid
Color
SPRINKLER MATERIAL
Stainless Steel SMO Titanium
TY-B
5.6
1/2 in. NPT
Standard
Response
Upright
135°F (57°C) Orange
1, 2, 3, 4 4
155°F (68°C) Red
175°F (79°C Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
Pendent
135°F (57°C) Orange
1, 2, 3, 4 4
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
Recessed
Pendent
a
Figure 13
135°F (57°C) Orange
1, 2 NAS
c
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
TY-B
8.0
3/4 in. NPT
Standard
Response
Upright
135°F (57°C) Orange
1, 2, 3, 4
N/A
d
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
Pendent
135°F (57°C) Orange
1, 2, 4
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
Recessed
Pendent
b
Figure 14
135°F (57°C) Orange
1, 2
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
NOTES:
1. UL Listed
2. C-UL Listed
3. LPCB Approved (LPCB Ref. No. 007q/01 and 007q/02)
LPCB EC Certicate of Conformity — 0832-CPD-2020
4. Lloyd’s Register Certicate of Fire Approval — SAS F060123
Lloyd’s Register EC Type Examination (Module B) Certicate — MED0650147
Lloyd’s Register EC (Module D) Certicate of Conformity — MED 0750238
a. Installed with Style 10 (1/2 in. NPT) Recessed Escutcheon
b. Installed with Style 40 (3/4 in. NPT) Recessed Escutcheon
c. NAS = No Approval Status
d. N/A = Not Available
TABLE A
SERIES TY-B STANDARD RESPONSE
5.6 AND 8.0 K-FACTOR PENDENT AND UPRIGHT SPRINKLERS
LABORATORY LISTINGS AND APPROVALS
