TABLE 18 – BACnet MS/TP points (CONT.)
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
DxPrsMn
Minimum Pressure Drop
Across the Evaporator Coil to
Prove Air Flow
BAV R/W 0.06 – 1.0 in of wc 16023 Only with FlexSys
E/W Econ En BBV 15008 Not Applicable
E/W Min BAV 16017 Not Applicable
E/W Mod BAO 14004 Not Applicable
E/W Rat Mod BAV 16114 Not Applicable
E/W Sat Mod BAV 16113 Not Applicable
E/W Temp BAI 13004 Not Applicable
E/WSadMod
Economizer PID Output Based
on Dew Point Temp
BAV R 0 – 100 % 16124
Only with
Economizer,
FlexSys with Dew
Point Control
EcRat Enable
Economizer Return Air Temp
Control:
1 = Enabled
0 = Disabled
BBV R/W - - 15007
EcSad Enable
Economizer Dew Point Temp
Control:
1 = Enabled
0 = Disabled
BBV R/W - - 15009 Only with FlexSys
EcSat Enable
Economizer Supply Air Temp
Control:
1 = Enabled
0 = Disabled
BBV R/W - - 15006
Fan Bp/Exh En
Status of the Constant Volume
Fan Output:
1 = On – Active
0 = Off – Inactive
BBO R/W - - 11001
Fan Out
Status of the Fan Out Dry
Contact:
1 = On Active
0 = Off – Inactive
BBO R/W - - 11004
Fan Speed
Analog Output to the Supply
Fan VFD in Volts
BAI R 0-10 Volts 13006
Only with VAV or
FlexSys
Fan VFD En
Binary Output to Energize the
Supply Fan VFD:
1 = On Active
0 = Off – Inactive
BBO R/W - - 11002
Only with VAV or
FlexSys
FanFlt
Indoor Fan Failure Alarm:
1 = Fault
0 = No Fault
BBV R - - 15113
FC Comp A BBV - - 15506 Not Applicable
FC Comp B BBV - - 15507 Not Applicable
