SECTION 4 - MODBUS RTU SLOT LIST
Modbus DF1 Count Logix Tag Description
10413 N12:19/9 313 SSS_HS.Alarms[2].9 SEC SSS: SPARE W2 B9
10414 N12:19/10 314 SSS_HS.Alarms[2].10 SEC SSS: SPARE W2 B10
10415 N12:19/11 315 SSS_HS.Alarms[2].11 SEC SSS: SPARE W2 B11
10416 N12:19/12 316 SSS_HS.Alarms[2].12 SEC SSS: SPARE W2 B12
10417 N12:19/13 317 SSS_HS.Alarms[2].13 SEC SSS: SPARE W2 B13
10418 N12:19/14 318 SSS_HS.Alarms[2].14 SEC SSS: SPARE W2 B14
10419 N12:19/15 319 SSS_HS.Alarms[2].15 SEC SSS: SPARE W2 B15
10420 N12:20/0 320 PC_141A.HiFreqTrip PRIMARY OIL PUMP DRIVE DID NOT MAKE SETPOINT
10421 N12:20/1 321 PC_141A.Fault PRIMARY OIL PUMP DRIVE FAULT
10422 N12:20/2 322 PC_141A.PDSL PRIMARY OIL PRESSURE LOW ALARM
10423 N12:20/3 323 PC_141A.PDSLL PRIMARY OIL PRESSURE LOW TRIP
10424 N12:20/4 324 PC_141A.PDSH PRIMARY OIL PRESSURE HIGH ALARM
10425 N12:20/5 325 PC_141A.PDSHH PRIMARY OIL PRESSURE HIGH TRIP
10426 N12:20/6 326 PC_141A.PDSHHZero PRIMARY OIL PRESSURE SENSORS WILL NOT ZERO
10427 N12:20/7 327 PC_141B.HiFreqTrip SECONDARY OIL PUMP DRIVE DID NOT MAKE
SETPOINT
10428 N12:20/8 328 PC_141B.Fault SECONDARY OIL PUMP DRIVE FAULT
10429 N12:20/9 329 PC_141B.PDSL SECONDARY OIL PRESSURE LOW ALARM
10430 N12:20/10 330 PC_141B.PDSLL SECONDARY OIL PRESSURE LOW TRIP
10431 N12:20/11 331 PC_141B.PDSH SECONDARY OIL PRESSURE HIGH ALARM
10432 N12:20/12 332 PC_141B.PDSHH SECONDARY OIL PRESSURE HIGH TRIP
10433 N12:20/13 333 PC_141B.PDSHHZero SECONDARY OIL PRESSURE SENSORS WILL NOT ZERO
10434 N12:20/14 334 ALARM SPARE W21 B14
10435 N12:20/15 335 ALARM SPARE W21 B15
10436 N12:21/0 336 SSS_LS.Alarms[0].0 PRI SSS FAULT: spare word0 bit0
10437 N12:21/1 337 SSS_LS.Alarms[0].1 PRI SSS FAULT: spare word0 bit1
10438 N12:21/2 338 SSS_LS.Alarms[0].2 PRI SSS FAULT: PHASE LOSS
10439 N12:21/3 339 SSS_LS.Alarms[0].3 PRI SSS FAULT: STARTER DISCONNECT
10440 N12:21/4 340 SSS_LS.Alarms[0].4 PRI SSS FAULT: POWER FAULT
10441 N12:21/5 341 SSS_LS.Alarms[0].5 PRI SSS FAULT: RUN SIGNAL MALFUNCTION
10442 N12:21/6 342 SSS_LS.Alarms[0].6 PRI SSS FAULT: CURRENT IMBALANCE
10443 N12:21/7 343 SSS_LS.Alarms[0].7 PRI SSS FAULT: CURRENT OVERLOAD
10444 N12:21/8 344 SSS_LS.Alarms[0].8 PRI SSS FAULT: HIGH INSTANTANEOUS CURRENT
10445 N12:21/9 345 SSS_LS.Alarms[0].9 PRI SSS FAULT: HIGH LINE VOLTAGE
10446 N12:21/10 346 SSS_LS.Alarms[0].10 PRI SSS FAULT: LOW LINE VOLTAGE
10447 N12:21/11 347 SSS_LS.Alarms[0].11 PRI SSS FAULT: FAILED SCR
10448 N12:21/12 348 SSS_LS.Alarms[0].12 PRI SSS FAULT: SPARE WORD0 BIT12
10449 N12:21/13 349 SSS_LS.Alarms[0].13 PRI SSS FAULT: SPARE WORD0 BIT13
10450 N12:21/14 350 SSS_LS.Alarms[0].14 PRI SSS FAULT: SPARE WORD0 BIT14
10451 N12:21/15 351 SSS_LS.Alarms[0].15 PRI SSS FAULT: SPARE WORD0 BIT15
10452 N12:22/0 352 SSS_LS.Alarms[1].0 PRI SSS FAULT: SPARE WORD1 BIT0
10453 N12:22/1 353 SSS_LS.Alarms[1].1 PRI SSS FAULT: SPARE WORD1 BIT1
10454 N12:22/2 354 SSS_LS.Alarms[1].2 PRI SSS FAULT: HIGH TEMPERATURE
10455 N12:22/3 355 SSS_LS.Alarms[1].3 PRI SSS FAULT: SPARE WORD1 BIT3
10456 N12:22/4 356 SSS_LS.Alarms[1].4 PRI SSS FAULT: SPARE WORD1 BIT4
10457 N12:22/5 357 SSS_LS.Alarms[1].5 PRI SSS FAULT: SPARE WORD1 BIT5
